德国JDT可旋转吊点TP-S型,旋转吊环

您现在的位置:网站首页 >> 产品专区 >> 进口品牌旋转吊环 >> 详细内容

德国JDT可旋转吊点TP-S型,旋转吊环

发布时间:2017-03-30  浏览:3825次  字号:

 德国JDT可旋转吊点TP-S型,旋转吊环

 10级标准的ENORM材料使其承载能力较之于上一代TAWGK系列产品在同等规格下提高了25%。

优势:
-清晰的刻度明确标出承重时链条所处倾斜角度,防止超过规定角度。
-附加的球轴承使其在负载状态下亦可转动。
-链环上的凸点可有效防止链环打结。
-内外表面均有电镀涂层,有效防止吊点被腐蚀。
-通过特殊机械加工手段改善基础面。
-球轴承磨损程度无需复杂工具即可校验。
-在所有受力方向下均保证4倍安全系数。
Grade 10ENORM material allows for an in-crease in working load limit of 25% without increasing swivel size compared to TAWSK.
The advantages:
-Marks on the swivel give a clear indication of inclination angels.
-Additional ball bearing system allows for smooth swiveling under load.
-Crimpfeature on the link prevents the link from kinking.
-Both intermsl and external surfaces are protected against corrosion by a tough galvanized coating.
-Improved swivel to surface contact is due to special machining.
-Ball bearing wear can be visually recognized by the gap on the wear ring without measuring instruments.
-Secred four times against breakage in all load directios.
德国JDT可旋转吊点TP-S型,旋转吊环
清晰的刻度明确标出承重时链条所处倾斜角度,防止超过规定角度。
附加的球轴承使其在负载状态下也可转动。
Marks on the swivel give a clear indication of inclination angles.
Additional ball bearing system allows for smooth swiveling under load.
利用承载能力对照卡可快速检测吊环缝隙,分析轴承磨损程度。
With the new WLL tables you can measure disposal stage.
